Balboa 3HP 240V 2Speed 56Y Spa Pump BB5235212S

Balboa 3HP 240V 2Speed 56Y Spa Pump BB5235212S

Enjoy strong, reliable jet power and efficient circulation with the Balboa 3HP 240V 2-Speed 56Y Spa Pump. Designed as a direct replacement for many Balboa, Ultrajet, and Ultimax pumps, this unit delivers smooth performance and quiet operation, making it a great choice for both upgrades and replacements.

Key Features & Benefits

• Powerful 3 HP output (4 HP competitive rating) for strong, consistent jet action in larger or multi-jetted spas.
• Dual-speed operation with high speed for hydrotherapy and low speed for efficient filtration and circulation.
• 56Y frame motor provides enhanced durability and compatibility with many standard spa equipment setups.
• Known for quiet, energy-efficient performance to help keep your spa relaxing and your energy use in check.
• Ideal replacement for existing Balboa, Ultrajet, or Ultimax pumps with matching horsepower, voltage, and plumbing.
• Versatile wet end can be rotated in 90-degree increments (ships in the 12 o’clock position) for flexible plumbing alignment.

Specifications

• Brand: Balboa
• Model: 3HP 240V 2-Speed 56Y Spa Pump
• Part number: BB5235212S
• Horsepower: 3 HP (4 HP competitive rating)
• Voltage: 230V / 240V, 60 Hz
• Amperage: 12A on high speed, 3.5A on low speed
• Motor frame: 56Y
• Connections: 2" intake and 2" discharge (MBT), approximately 3" outside diameter
• Wet end orientation: Rotatable in 90-degree increments, ships in 12 o’clock position
• Application: Replacement or upgrade pump for compatible hot tub and spa systems
